Figure 92. Set the anti-tilt wires to the locked position and tightening the nuts
4. For HM Configuration, connect the cables connected from processor heater manager module to heater and sensor ports on
the system board.
Next steps
1. Install the 2U sled on 1U node
2. Follow the procedure listed in the After working inside your system.
System battery
This is a service technician replaceable part only.
Replacing the system battery
Prerequisites
WARNING:
There is a danger of a new battery exploding if it is incorrectly installed. Replace the battery only
with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the
manufacturer's instructions. See the Safety instructions that came with your system for more information.
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
1. To remove the battery:
a. Use a plastic scribe to pry out the system battery.
CAUTION:
To avoid damage to the battery connector, you must firmly support the connector while installing
or removing a battery.
120 Installing and removing system components
