Table 2. Rear view of the sled (continued)
Item Ports, panels, or slots Icon Description
4 Bottom layer 1U Power
Distribution Board (PDB)
N/A Provides power to bottom layer
cooling fans
5 Bottom layer 1U guiding pin N/A Guiding pin for the 1U sled.
6 Upper layer 2U Power
Distribution Board (PDB)
N/A Provides power to upper layer cooling
fans
System configurations - inside view for PowerEdge
XR8620t
Figure 3. Inside view of the PowerEdge XR8620t sled
1.
2U Power Distribution Board (PDB) 2. System Board
3. Riser 1 4. M.2 Direct Riser
5. Processor 6. 2U sled cooling fan
Locating the Express Service Code and Service Tag
The unique Express Service Code and Service Tag are used to identify the system.
The information tag is located on the front of the system that includes system information such as iDRAC MAC address,
Express Service Tag label, Quick Resource Locator.
12
Dell PowerEdge XR8620t system configurations and features
