System weight
Table 4. PowerEdge XR8620t system weight
System configuration Maximum weight
1x DIMM, 1x M.2 NVMe SSDs on M.2 riser 5.197 kg (11.45 pound)
8x DIMMS, 2x M.2 NVMe SSDs on M.2 riser 5.326 kg (11.74 pound)
1x DIMM, Riser1, Riser2 without PCIe cards 4.071 kg (8.97 pound)
8x DIMMS, Riser1, Riser2 with PCIe cards 7.071 kg (15.58 pound)
8x DIMMS, 2x M.2 NVMe SSDs on M.2 riser, Riser1, Riser2
with PCIe cards
7.149 kg (15.76 pound)
Processor specifications
Table 5. PowerEdge XR8620t processor specifications
Supported processor Number of processors supported
4
th
Generation Intel Xeon Scalable and Edge-Enhanced
processors with up to 32 cores
One
NOTE: It is recommended to use a maximum of two add-in cards with SPR EE-LCC CPU. Three add-in cards are
supported, but this may result in an overall system performance degradation. .
Cooling fan specifications
The PowerEdge XR8620t system supports up to eight cabled cooling fans for airflow.
Supported operating systems
The PowerEdge XR8620t system supports the following operating systems:
● Red Hat Enterprise Linux
● SUSE Linux Enterprise Linux
● WindRiver Solution
● VMware
For more information, go to OS support.
System battery specifications
The PowerEdge XR8620t system supports CR 2032 3.0-V lithium coin cell system battery.
Memory specifications
The PowerEdge XR8620t system supports the following memory specifications for optimized operation.
16
Technical specifications
