Figure 38. Removing the 2U top sled from the 2U node
Next steps
Replace the 2U top sled from the 2U node.
Installing the 2U top sled on the 2U node
Prerequisites
1. Follow the safety guidelines listed in Safety Instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
1. Align the 2U top sled horizontally and place it on top of the 2U node.
CAUTION: Support the 2U top sled with both hands while placing it on the 2U node.
2. Using Phillips 1 screwdriver, tighten the side screws and front captive screw that secure the 2U top sled on the 2U node.
76
Installing and removing system components
