F
Attach the nose unit to this machine.
Tighten until it does not move, and then loosen about two rotations and set the scale to "0."
Loosen
Tighten
Turn here
3.
Set the lock lever.
Set the lock lever at or position.
For details on the setting position of the lock lever, see P. 62 "Setting the Lock Lever".
Lock lever
Press slightly, then lower it.
4.
Install the cutter and set the engraving depth.
A
Close the front cover.
B
Press [ENTER/PAUSE].
When the initial operation is complete, the main screen appears.
Starting Engraving
45
Chapter 3 Basic Engraving Methods
