E
Fasten the hose with the clamp close to the back of this machine.
Fasten at the position of the retaining band on the hose.
Fasten at the
position where
you hear a
"click."
Opening the clamp
Closing the clamp
MEMO
Hose
Clamp
Workpiece table
Front
F
Slowly move the spindle head by hand to the front left.
Be careful not to apply strong impact.
Top
G
Fasten the hose with the (two) clamps in the center of this machine.
Clamp Clamp
Retaining band
Other Basic Operations
60
Chapter 3 Basic Engraving Methods
