Dieci Pegasus - Liquid Crystal Display

Getting to know and using tha machine
Integrated devices
C/58
Model E.T. PEGASUS
- CAUTION: - Read the SAFETY REGULATIONS (in this manual) carefully for the safety of all personnel and the machine.
A
B
C
(g.101/C)
1 2 3
4
891211 7 6
5
Vkmip/h
X12 X11X9X7X5
X10 X6
X8
X13
X14
X1
DP9
COL1 DP5
RPM
AM
LIQUID CRYSTAL DISPLAY
The following functions are displayed:
- Hour counter (6 gures including one decimal and an hourglass) (g.101/C Pos.“C”).
- Clock (4 gures) (g.101/C Pos.“A”).
- Tachymeter (3 gures including one decimal, plus km/h, m/h and mph) (g. 101/C Pos.“C”).
- Odometer (6 gures including one decimal plus km and miles) (g.101/C Pos.“C”).
- Neutral gear engaged (g.101/C Pos.“B”).
- Engine errors (electronic engine only)
(large ashing E + 3 gures above) (g.101/C Pos. “A”, g.101/C Pos.“B”, g.101/C Pos.“C”)
- Service (large ashing S + number of hours to go before a service is required) (g.101/C Pos.“A”, g.101/C Pos.“B”)
Tachymeter (optional)
The tachymeter allows you to display the speed of the machine in real time.
Odometer (optional)
The odometer allows you to view the kilometres travelled by the machine. This instrument is in conjunction with the tachymeter.
