Dieci Pegasus - Instruments Inside the Cab

Getting to know and using the machine
C/14
Model E.T. PEGASUS
- CAUTION: - Read the SAFETY REGULATIONS (in this manual) carefully for the safety of all personnel and the machine.
INSTRUMENTS INSIDE THE CAB
(g.16/C)
1
2
4
5
6
9
7
8
12
13
14
15
3
16
17
10
Dashboard with air vents1.
Adjustable steering column.2.
Right-side dashboard3.
Steering wheel adjustment lever4.
Turret/boom movement joystick5.
“INCHING” pedal6.
Brake pedal7.
Accelerator pedal8.
Steering wheel9.
Ignition key 10.
Machine function selector11.
Load monitoring display12.
Left-side dashboard13.
Spirit level14.
Gear lever15.
Multifunction lever16.
Instrument cluster17.
11
(g.16/C)
