USING THE LOAD TABLES AND BOOM INDICATORS
- CAUTION -
For your own safety and the integrity of the machine, comply with the information provided below.
The load tables regarding your machine are in the notebook in the cab.
- CAUTION -
The limits indicated in the load tables refer to the machine at a halt on wheels or stabilizers and on level ground.
Do not lift or extend the boom when the machine is in motion.
Retract the boom completely and lower it as far as possible before moving with a load.
Check which boom attachment is assembled on the machine and then consult the relevant load table in the cab.
Before raising or putting down a load, you must know how much it weighs.
Ensure the centre of gravity of the load does not exceed 500 mm measured from the heels of the forks.
- CAUTION -
The centre of gravity may not be at the centre of the load, therefore it is necessary to locate its position.
