Dieci Pegasus - Torque Table for Hydraulic Fittings

Mod. E.T. PEGASUS
D/52
Maintenance and adjustment
- CAUTION: - Read the SAFETY REGULATIONS (in this manual) carefully for the safety of all personnel and the machine.
60° oval insert - BSP thread
THREAD
N.m
1/18-28
12-14
TORQUE TABLE FOR HYDRAULIC FITTINGS
1/4-19
14-16
3/8-19
25-28
1/2-14
45-60
5/8-14
55-70
3/4-14
90-110
1”-11
120-140
1”1/2-11
200-245
1”1/4-11
170-190
60° oval insert - METRIC thread
THREAD
N.m
10x1
12-14
12x1,5
13-15
14x1,5
15-18
16x1,5
25-28
18x1,5
27-30
22x1,5
50-60
26x1,5
60-75
30x1,5
110-130
28x1,5
80-100
DIN FITTINGS SERIES / RANGE “L”
THREAD
N.m
12x1,5
13-15
14x1,5
15-18
16x1,5
25-28
18x1,5
27-30
22x1,5
50-60
26x1,5
30-75
36x1,5
120-140
30x2
85-105
45x1,5
170-190
52x1,5
190-230
DIN FITTINGS SERIES / RANGE “S”
THREAD
N.m
14x1,5
15-18
16x1,5
25-28
18x1,5
27-30
20x1,5
43-54
22x1,5
50-62
30x2
90-110
24x1,5
60-75
36x2
125-145
42x2
170-190
52x2
200-245
