Cleaning/Replacing the cartridges engine air lter elec-
tronic
1. Place the machine on a at and level surface.
2. Switch off the engine and remove the ignition key.
Place a “maintenance work in progress” sign in the cab.
3. Open and fasten the bonnet.
4. Pull the locking levers (g.36/D Pos.“1”) located on the
four corners of the lter lid (g.35/D Pos.“2”) towards you
5. Remove the lid (g.35/D Pos.“2”).
6. Push the internal handle (g.37/D Pos.“1”) towards the
engine (as indicated by the arrow) and pull towards you
to remove the secondary lter.
7. Allow the paper lter (g.38/D Pos.“1”) to slide out of its hou-
sing by turning the end with the seal upside down. Hold one
hand below the seal to ensure it does not fall and break.
8. Pull the tongue (g.39/D Pos.“2”) on the side or the cen-
tral plastic (g.39/D Pos.“3”) towards you to remove the
primary lter (g.39/D Pos.“1”).
9. Clean or replace the lter and reassemble all the parts
by reversing the procedure described above.
2
1
C1
1
(g.35/D)
1
3
2
(g.36/D)
(g.37/D)
(g.38/D)
(g.39/D)
1
