14
GNX3000 Owner’s Manual
7. Displays
The Displays give feedback of the various functions that are being used in the
GNX3000, including preset name, editing functions,
tuner, utility menus, and drum
machine settings.
8. Preset Bank LEDs
The Preset Bank LEDs indicate whether the selected preset resides in the User,
Factory 1, or Factory 2 banks.
9. Data Wheel
The DATA WHEEL is a multi-function control used for selecting presets and editing
preset parameters. It is also used for adjusting the settings of the Drum Machine,
Utilities, Output Setup, Mic/Line Routings, and Recording Setup menus.
10. Status Indicator LEDs (Clip, Wah, and USB Active)
There are three Status Indicator LEDs. The CLIP LED illuminates when one of the
four input signals clip (is at or above their maximum input level), The WAH PEDAL
LED lights when the Wah pedal is active. The
USB LED lights when the USB
connection is active.
11. Control Panel Buttons
The Control Panel buttons are used to select the GNX3000’s Footswitch Modes,
Output Setups, and Utility functions, and to store Amp/Cabinet Model edits and
Preset changes. They also access the GNX3000’s Drum Machine functions as well
as mic/line routing and USB input source routing for recording. The buttons are
labeled as follows:
MODE - This button changes the functionality of the DOWN/UP FOOTSWITCHES
and FOOTSWITCHES 1-5 (see the Footswitch Functions for Modes section on page
94
). Each time the mode is changed, the name of teh new mode is displayed
briefly.
OUTPUT SETUP - This button selects one of the GNX3000 Audio Output Setups:
Stereo All, Mono All, Mono 1/4”, Mono XLR, Split 1 and Split 2. Stereo and Mono
All have all the input sources (guitar, mic, line inputs, drums, and audio playback
from USB) routed to both output pairs in either stereo or mono respectively. Split 1
routes the guitar signal to just the 1/4” OUTPUTS while all other sources are routed
out the XLR OUTPUTS. Split 2 is the same as Split 1 but the guitar signal is also
routed out the XLR OUTPUTS. See page 24 for more information about Speaker
Compensation for XLR and 1/4” OUTPUTS
.
UTILITY - This button accesses the GNX3000’s global functions including:
Volume Pedal Update, Expression Pedal Calibration, Preset Bounceback, Bank
Naming, MIDI Channel selection, Sysex Bulk Dump, MIDI Preset Dump, User
14
Getting Familiar with the GNX3000
GNX3000 Owner’s Manual
