Technical data
146 Instructions for use Oxylog 3000 plus SW 1.n
Leakage
Alarm Only with NIV off in VC modes:
When VTe <60 % of VTi over the last 25 seconds
plus the duration of one breathing cycle or
8 ventilation cycles
Data communication (option)
Exported data Measured values
Curves
Alarms
Alarm settings
User settings
For the data communication protocol contact
DrägerService.
Baud rate 19200
Data bits 8
Parity Even
Stop bit 1
Operating data
Power supply
Power supply
Oxylog 3000 plus
Input voltage
24 V ±6 VDC
The power supplies
(AC/DC power pack and
DC/DC converter) are
specified as part of
Oxylog 3000 plus.
Power consumption
With battery charging maximum 2.4 A at 19 VDC
Operating time with a new
and fully charged internal
battery without mains
power supply
– in typical ventilation
without CO
2 sensor,
reduced display
brightness
– in typical ventilation
Approx. 9.5 hours
Approx. 7.5 hours
