Assembly
46 Instructions for use Oxylog 3000 plus SW 1.n
Connecting the disposable breathing circuit for pediatric patients
1 Connect the blue flow measuring line (B) to the
blue labeled connector.
2 Connect the transparent flow measuring line (A)
to the other connector.
3 Connect the breathing hose (C) to the
expiratory port on Oxylog 3000 plus.
When connecting a breathing hose, check that the
hose setting in the settings window corresponds to
the connected hose.
WARNING
Risk of patient injury
If the tidal volume is less than 250 mL, use a
pediatric breathing circuit.
If the tidal volume is more than 250 mL, use an
adult breathing circuit.
013
