Monitoring
94 Instructions for use Oxylog 3000 plus SW 1.n
Data communication (option)
With the data communication option, measured
values, curves, alarms, and settings can be
transferred using the MEDIBUS.X-protocol.
MEDIBUS.X is a software protocol for the transfer
of data between Oxylog 3000 plus and an external
medical or non-medical device (e.g., patient
monitors or computers for data management
systems).
The combination of Oxylog 3000 plus and an
external device must comply with IEC/EN 60601-1
and IEC/EN 60601-1-2.
For more information, refer to "MEDIBUS.X, Rules
and Standards for Implementation"
(90 52 607) and "MEDIBUS.X, Profile Definition for
Data Communication V1.n" (90 52 608).
Connecting an external device
1 Connect the external device to the data
communication cable 57 05 301.
2 Connect the data communication cable to
Oxylog 3000 plus.
Serial port
The port for the data communication cable
corresponds to an RS-232 interface in accordance
with EIA RS-232 (CCITT V.24/V.28).
Requirements for the electrical
properties of connected devices and
networks
The serial port is only suitable for connecting
devices or networks which have a maximum
nominal voltage of 24 VDC on the network end and
which comply with one of the following standards:
– IEC 62368-1: Ungrounded SELV circuits
– IEC 60601-1 (from 2nd edition): Touchable
secondary circuits
Connections to IT networks
Connecting this device to a network that
incorporates other devices or making subsequent
changes to that network can lead to new risks for
patients, users, and third parties. Before the device
is connected to the network or the network is
changed, these risks must be identified, analyzed
and evaluated by the hospital's IT officer according
to the standard IEC 80001-1 (Risk management for
IT networks with medical devices). On the basis of
the results, appropriate measures have to be taken.
Examples of subsequent changes to the network:
– Changing the network configuration
– Removing devices from the network
– Adding new devices to the network
– Performing upgrades or updates on devices
that are connected to the network
WARNING
Risk due to incorrectly transmitted data
All data sent to other devices via the
MEDIBUS.X interface of the device may be
displayed incorrectly or incompletely. They
are therefore only for information purposes.
Do not use data displayed on other devices for
diagnostic or therapeutic decisions.
Do not use data displayed on other devices for
patient or device monitoring.
