Operation
66 Instructions for use Oxylog 3000 plus SW 1.n
– Hose type
The selected hose type must match the hose
type in use. Otherwise a correct volume
measurement cannot be guaranteed.
–CO
2 cuvette type (optional)
VC-AC
VC-AC – Volume Controlled – Assist Control
For synchronization with the patient's inspiratory
efforts. For patients with partial spontaneous
breathing.
The mandatory breaths are synchronized with the
patient's spontaneous inspiratory efforts when the
trigger is activated and the trigger sensitivity is set.
The actual respiratory rate may be higher than the
set respiratory rate RR.
Successful patient triggering is briefly indicated by
an asterisk (*) on the left side of the curve window.
Activating and setting the trigger
1 Press the Settings key (A) until the
Trigger parameter is displayed.
2 Select the line Trigger on the display and then
set and confirm the value with the rotary knob.
Small value = high sensitivity.
The ventilation mode AC
is shown on the display.
1373717114537171
NOTE
The cuvette windows of the reusable cuvette and
disposable cuvette have different optical proper-
ties. Therefore, the correct cuvette type must be
selected in the settings menu. Otherwise the zero
point will be shifted by as much as ±8 mmHg CO
2.
NOTE
If a trigger value is set in ventilation mode VC-
CMV, the ventilation modus changes to VC-AC.
00537170
