Instructions for use Oxylog 3000 plus SW 1.n 45
Assembly
Connecting the disposable breathing circuit for adults
1 Connect the flow measuring lines (A) to
Oxylog 3000 plus. Correct alignment is
indicated by a notch on the connector, which
must point away from the breathing hose. If it is
incorrectly seated, incorrect values will be
measured.
2 Connect the breathing hose (B) to the
expiratory port on Oxylog 3000 plus.
When connecting a breathing hose, check that
the hose setting in the settings window
corresponds to the connected hose.
NOTE
Using a disposable hose may reduce the risk of
cross-infection.
013
NOTE
Disposable hoses are shipped clean but
non-sterile.
