Technical data
Service Instructions 867 - 04.0 - 10/2019 145
1-needle long arm machines with integrated motor (-M)
Subclasses: 867-
-190020-70-M ECO
-190040-70-M ECO
-190122-70-M
-190322-70-M
-190342-70-M
-190142-70-M
Type of stitches Double lockstitch 301
Vertical hook, large (L) x x x
Vertical hook, extra-large (XXL) x x x
Number of needles 1
Needle system 134-35
Maximum needle strength [Nm] 180
Maximum sewing thread size 80/3-10/3
Stitch length, forwards/backwards
[mm]
12/12
Number of adjustable stitch lengths 1 1 1 2 2 1
Maximum s.p.m. 3000
Number of stitches on delivery 3000
Maximum stroke height
(*only with reversing mechanism)
20 20 20* 20* 20* 20*
Maximum sewing foot stroke 9
Positive operating pressure [bar] 6
Air consumption [NL] 0.7
Length/width/height [mm] 1090/220/460
Weight/with direct drive [kg] 89
Rated voltage [V, Hz] 230, 50/60
Rated power [W] 375
