Technical data
146 Service Instructions 867 - 04.0 - 10/2019
2-needle long arm machines with integrated motor (-M)
Subclasses: 867-
-290020-70-M ECO
-290040-70-M ECO
-290122-70-M
-290322-70-M
-290342-70-M
-290142-70-M
-290342-100-M
(Long arm)
Type of stitches Double lockstitch 301
Vertical hook, large (L) x x x
Vertical hook, extra-large (XXL) x x x x
Number of needles 2
Needle system 134-35
Maximum needle strength [Nm] 180
Maximum sewing thread size 80/3-10/3
Stitch length, forwards/
backwards [mm]
12/12
Number of adjustable stitch
lengths
1112212
Maximum s.p.m. 3000 2500
Number of stitches on delivery 3000 2500
Maximum stroke height
(*Only with reversing
mechanism)
20 20 20* 20* 20* 20* 20*
Maximum sewing foot stroke 9
Positive operating pressure [bar] 6
Air consumption [NL] 0.7
Length/width/height [mm] 1090/220/460 1390/
220/
460
Weight/with direct drive [kg] 89 99
Rated voltage [V, Hz] 230, 50/60
Rated power [W] 375
