5.3.7 Drive Profiles parameters
These parameters have to be set for every Drive Profile:
Parameter Possible Values Default Rev HHP Lite Std Adv
Forward Speed @ Maximum 10 – 100 % N/A -,A,C
Forward Speed @ Minimum 5 – 100 % 5% C
Forward Acceleration 10 – 70 % 40 % -,A,C
Forward Deceleration 15 – 100 % 60 % -,A,C
Reverse Speed @ Maximum 10 – 100 % N/A -,A,C
Reverse Speed @ Minimum 5 – 100 % 5% C
Reverse Acceleration 10 – 70 % 70 % -,A,C
Reverse Deceleration 15 – 100 % 30 % -,A,C
Turning Speed @ Maximum 20 – 100 % N/A -,A,C
Turning Speed @ Minimum 5 – 100 % 5% C
Turning Acceleration 10 – 70 % 40 % -,A,C
Turning Deceleration 15 – 100 % 70 % -,A,C
Turn Damping 10 – 100 % 40% C -
Non-Linear Turn No / Yes No C -
Short Throw Shape 100 – 200 % 200 % C -
Short Throw Travel 100 – 200 % 100 % C -
Grip 5 – 100 % 100% C
Damping Point 10 – 100 % 40 % -,A
These parameters are set for all drive profiles at once:
Parameter Possible Values Default Rev HHP Lite Std Adv
Speed Damping 5 – 100 % 40 % C -
Min To Max Decel Ratio 4 – 100 % 20 % -,A,C -
Speed x Turn for Grip 5 – 100 % 100 % C -
Accel Out Of A Turn For Grip 0 – 200 % 100 % C -
Accel Into A Turn For Grip 0 – 200 % 100 % C -
Turning @ Full Speed 5 – 100 % 100 % C -
Turning Accel @ Full Speed 100 – 300 % 100 % C -
