5.3.10.7 UCM Joystick Swap Left/Right
Parameter Possible Values Default Rev HHP Lite Std Adv
UCM Joystick Swap
Left/Right
No / Yes No -,A,C -

 
If the Master Remote is mounted upside-down (for example with chin or tray
applications), set UCM Joystick Swap Left/Right to 'Yes'.
This parameter only applies to the Master Remote joystick, not to the Remote Joystick
Module (RJM) or the Attendant Control Module (ACU) joysticks, or to drive switches
connected to the Master Remote. To apply Left/Right joystick swap to the RJM
joystick, use the
RJM Joystick Swap Left/Right parameter (5.3.10.14). To apply
Left/Right joystick swap to the ACU joystick, use the
ACU Joystick Swap Left/Right
parameter (
5.3.10.10).
5.3.10.8 Rotate UCM Joystick
Parameter Possible Values Default Rev HHP Lite Std Adv
Rotate UCM Joystick No / Yes No
C
-

 
If this parameter is set to 'Yes', the joystick operation of the Master Remote is rotated
by 90°.
Parameter
Value
Deflection Driving
direction
Forward  Forward
Right  Right
Reverse  Reverse
No
Left  Left
Forward  Right
Right  Reverse
Reverse  Left
Yes
Left  Forward
To rotate the other way around (Forward  Left), set
Joystick Swap Forward / Reverse
(
5.3.8.8) and UCM Joystick Swap Left/Right (5.3.10.7) to 'Yes' as well.
Use a forward/backward symmetrical restrictor plate (for example a circular or a
square restrictor plate) if this parameter is set to 'Yes'.
5.3.10.9 ACU Enable
Parameter Possible Values Default Rev HHP Lite Std Adv
ACU Enable No / Yes Yes
-,A,C
-

 
If an Attendant Control Unit (ACU) is fitted, set this parameter to 'Yes' to allow the ACU
to take control over the chair.
If no ACU is fitted, setting this parameter to 'Yes' will slightly decrease the performance
of the chair, because the DX System will regularly search for the presence of an ACU.
