5.3.8.7 Joystick Source
Parameter Possible Values Default Rev HHP Lite Std Adv
Joystick Source (RJM) No / Yes No -,A
Master
ACU
RJM
Display
ARC
ExtNV1
ExtNV2
None
Joystick Source Master C
Rev -,A:
Selects whether the Drive Profile will use the built-in joystick of the Master Remote or
an external RJM-based input control device. The ACU can only be used in Drive
Profile 6.
Rev C:
In this revision every Drive Profile can have its own type of Secondary Remote (RJM,
ACU and ARC). Simply choose the joystick that is applicable for each Drive Profile.
There can not be more than one joystick of the same type simultaneously connected
to the DX System. For example: one RJM-type joystick, an ACU and an ARC can be
simultaneously connected, but not two RJM-type joysticks. RJM-type joysticks include:
all DX-RJM joysticks, switch modules and the Sip and Puff module.
Some Master Remotes do not use Display, ExtNV1 or ExtNV2. Refer to the manual of
the Master Remote in question for more details.
All revisions:
If you select ACU, make sure that the
ACU Enable parameter (5.3.10.9) is set to 'Yes'.
If you select RJM, make sure that the
RJM Enable parameter (5.3.10.13) is set to 'Yes'.
If a Drive Profile is selected that has the RJM as the Joystick Source, and the RJM is not
connected to the DX System, a Module Fault (flash code 1) will occur.
HHP Selection of the Joystick Source (Rev. C)
• Connect the alternate input device, DX-RJM, DX-5SW etc.
• Switch on the DX System and select the desired Drive Profile with a Mode button.
• Insert the HHP and cycle through the available options (Speed/Acceleration etc.)
• The final option will be the Joystick Source, as shown below.
• Press Up/Down to select the input device, Exit to confirm.
83
