Dynamic DX User Manual

6.2 Secondary Remotes
A Secondary Remote is a secondary user input device, for example an attendant
joystick. A Secondary Remote
• converts user input (the joystick or the switches, dependent on the type of
Secondary Remote) to speed and direction signals, and
• sends the speed and direction signals as DX BUS messages to the Master
Remote via the DX BUS.
To use a Secondary Remote, select it as the
Joystick Source
GBK60348
: Issue 1 – October 2007
98
(see 5.3.8.7) in one of the
Drive Profiles (see
5.3.2).
6.2.1 Available Secondary Remotes
Secondary Remote Applications
Attendant joystick
Attendant can take drive control with Attendant/User switch
Attendant can adjust chair speed
DX-ACU1
Dual Control
Attendant joystick
User joystick for Master Remotes without joystick
User joystick mountable on the armrest or away from it
DX-RJM
Compact chin remote
Remote Joystick
Module
Users without finer hand movement
Situations where a normal joystick can be damaged
DX-RJM-HD
Heavy Duty Joystick
Full proportional control with very little movement or force
Completely sealed - can be used as a tongue joystick
DX-RJM-MINI
DX Mini Joystick
Zero force optical operation
Users with very little strength in their hand/fingers
DX-RJM-VIC-CCD
Finger Steering
Control
Full proportional control
Finger movement of 2 mm per direction is enough
Driven by four momentary switches,
Either separate switches or
Switches combined in one unit (for example the wafer switch)
DX-ACC4
Provides up to eight driving directions
Four Switch Interface
