ECKELMANN Case Controller UA 4 E Series - Page 200

Firmware V3.13
21.04.2021
200/466
•
•
•
Menu 2-1-3 Zone 1T Toggle
COOLING 1A POS: XXXXX Entry Default
Setpoint R2.1 XXX °C Supply air temperature
setpoint
--, -10..20
Hystersis R2.1 X K Supply air temperature
hysteresis setpoint;
shown only when on-off
control is set (Menu
2-1-1)
1..8
Setpoint R4.1 XXX °C Return air temperature
setpoint
--, -10..20
Hystersis R4.1 X K Return air temperature
hysteresis setpoint;
shown only when on-off
control is set (Menu
2-1-1)
1..8
Menu 2-1-4 Zone 2T Toggle
COOLING 2A POS: XXXXX Entry Default
Setpoint R2.2 XXX °C Supply air temperature
setpoint
--, -10..20
Hystersis R2.2 X K Supply air temperature
hysteresis setpoint;
shown only when on-off
control is set (Menu
2-1-2)
1..8
Setpoint R4.2 XXX °C Return air temperature
setpoint
--, -10..20
Hystersis R4.2 X K Return air temperature
hysteresis setpoint;
shown only when on-off
control is set (Menu
2-1-2)
1..8
Menü2-2Defrost
DEFROST POS: XXXXX
1 Zone 1 Move to menu 2-2-1
2 Zone 2 Move to menu 2-2-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-2-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Zone 2T Toggle Move to menu 2-2-4; shown only when two-zone operation is set (Menu 6-1) and when
setpoint toggle is not deactivated (Menu 3-3)
