Menu2-4Alarm
ALARM POS: XXXXX
1 Zone 1 Move to menu 2-4-1
2 Zone 2 Move to menu 2-4-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-4-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Zone 2T Toggle Move to menu 2-4-4; shown only when two-zone operation is set (Menu 6-1) and when
setpoint toggle is not deactivated (Menu 3-3)
Menu 2-4-1 Zone 1
ALARM 1 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
0..30 8 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
Menu 2-4-2 Zone 2
ALARM 2 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
0..30 8 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
Menu2-4-3Zone1TToggle
ALARM 1A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
0..30 8 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
Menu 2-4-4 Zone 2T Toggle
ALARM 2A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
0..30 8 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
