Menu 2-5 Frame Heater
FRAME HTR POS: XXXXX
1 Mode frm htr Move to menu 2-5-1
2 Setpoint frm htr Move to menu 2-5-2
3 Mode altern. Move to menu 2-5-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Setpoint altern. Move to menu 2-5-4;not shown when setpoint toggle is deactivated (Menu 3-3)
Menu 2-5-1 Frame Mode
Selectionismadeaccordingtoentry.Checkmarkshowscurrentsetting.
MODE POS: XXXXX Entry Default
Fixedruntime√ √
Enthalpy-ctrl rtm
Menu2-5-2FrameSetpoints
SETPOINTS POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Displays set frame mode (Menu 2-5-1) fixed run time
Run Time XXX % Fixed on time, shown only when mode set to
Fixed OT (Menu 2-5-1)
--, 0..100 100 %
emerg.run time XXX % On time in loss of humidity or room air
temperature (via CAN bus); shown only when
mode set to Enthalpy Control (Menu 2-5-1)
--, 0..100 100 %
enthalp. offs. XXX % Offset for on time when enthalpy control is
activated (via CAN bus); shown only when mode
set to Enthalpy Control (Menu 2-5-1)
-50..50 0 %
Invert Output xxx Inversion of the function of the frame heater
output (terminals 91/92)
↑,↓,(ON/OFF) ON
Menu 2-5-3 Toggle Mode
MODE ALT. POS: XXXXX Entry Default
Fixedruntime√ √
Enthalpy-ctrl rtm
Menu 2-5-4 Setpoint Toggle
TOG. SETP. POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Displays set frame mode (Menu 2-5-3) fixed run time
Run Time XXX % Fixed on time, shown only when mode set to
Fixed OT (Menu 2-5-3)
--, 0..100 100 %
