ECKELMANN Case Controller UA 4 E Series - Page 284

Firmware V3.13
21.04.2021
284/466
•
•
•
•
•
Menu 2-2-3 Zone 1T Toggle
DEFROST 1A POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint --, 5..20 5 °C
Wait Time XX m Waiting time setpoint between cooling and
defrost
0..15 0 min
Drip Time X m Waiting time (drip time) setpoint between defrost
and cooling
0..15 0 min
Menu 2-2-4 Zone 2T Toggle
DEFROST 2A POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint --, 5..20 5 °C
Wait Time XX m Waiting time setpoint between cooling and
defrost
0..15 0 min
Drip Time X m Waiting time (drip time) setpoint between defrost
and cooling
0..15 0 min
Menu2-3Notusedwiththiscontrollertype.
Menu 2-4 Alarm
ALARM POS: XXXXX
1 Zone 1 Move to menu 2-4-1
2 Zone 2 Move to menu 2-4-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-4-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Zone 2T Toggle Move to menu 2-4-4; shown only when two-zone operation is set (Menu 6-1) and
when
setpoint toggle is not deactivated (Menu 3-3)
Menu 2-4-1 Zone 1
ALARM 1 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
-10..30 6 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
