ECKELMANN Case Controller UA 4 E Series - Page 320

Firmware V3.13
21.04.2021
320/466
•
•
•
•
•
Menu 2-3-1 Zone 1
FANS 1POS: XXXXX Entry Default
Fan Delay XXX °C Fan start temperature setpoint --, -20..20 –°C
Menu 2-3-2 Zone 2
FANS 2POS: XXXXX Entry Default
Fan Delay XXX °C Fan start temperature setpoint --, -20..20 –°C
Menu 2-3-3 Zone 1T Toggle
FANS 1APOS: XXXXX Entry Default
Fans Delay XXX °C Fan start temperature setpoint --, -20..20 –°C
Menu 2-3-4 Zone 2T Toggle
FANS 2APOS: XXXXX Entry Default
Fans Delay XXX °C Fan start temperature setpoint --, -20..20 –°C
Menu 2-4 Alarm
ALARMPOS: XXXXX
1 Zone 1 Move to menu 2-4-1
2 Zone 2 Move to menu 2-4-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-4-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Zone 2T Toggle Move to menu 2-4-4; shown only when two-zone operation is set (Menu 6-1) and when
setpoint toggle is not deactivated (Menu 3-3)
