Epson Artisan 810/835/837/710/725/730/Epson Stylus Photo PX810FW/TX810FW/PX820FWD/TX820FWD/PX830FWD/PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD
Revision G
ADJUSTMENT Adjustment without Using Adjustment Program 237
Confidential
5. Press “+” displayed on the four corners in order using the touch pen.
Figure 5-49. Touch Panel Adjustment (4)
6. If you retry the adjustment, press the area other than LCD and start from Step 5
once again. When saving the result of adjustment, press LCD.
Figure 5-50. Touch Panel Adjustment (5)
7. When the confirmation pattern appears, press “+” displayed in the middle of the
panel.
Figure 5-51. Touch Panel Adjustment (6)
8. When “Complete!” appears on LCD, press the “CD/DVD tray” button to return to
the menu, and press the “power” button to complete the adjustment. If
“Complete!” is not displayed, press “CD/DVD tray” button and perform Step 7
once again.
Figure 5-52. Touch Panel Adjustment (7)
Touch panel to coordinate them
Touch LCD area. [Save]
Touch area outside of LCD. [Retry]
Press [CD/DVD] button to retry.
+
Complete!
Push [CD/DVD] Button
