Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 103
Confidential
5
Check the status of the CR Encoder FFC
Check the CR Encoder FFC to make sure that it is not inserted obliquely or
damaged.
Go to step 6
 Properly connect the CR Encoder FFC.
 Replace the CR Encoder FFC (head FFC) in
the case of damage.
6
Perform CR Motor operation check
Does the CR Motor operate (rotate)?
Go to step 7 Replace the CR Motor.
7
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Replace the Printer Mechanism. End
Step Check and measure Yes No

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
