Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Configuration and operating principles Operating principles 46
Confidential
3.3.2.4 PG type
This product has four types of PGs. The following describes the details of PGs. Each PG is determined by up to where the Carriage moves with reference to the APG Lever. PG set
once is held until the next PG shift sequence.
Distance from
0-digit (mm)
Carriage
operation
position and
PG (mm)
PG (mm)
1.55 1.85 2.35 3.0
PG Position
PG1 PG2 PG3 PG4
Application
Printing plain paper (Single)
(Standard), Photo paper
Printing plain
paper (Fine),
Post card,
Photo matte
paper, Duplex
printing, or to
avoid rubbing
To avoid
rubbing
(Uni-d)
Envelope
(Uni-d)
APG reset standby
position
APG shift standby
position
APG reset complete
position
289.627 243.332
271.07
PG 3 set position
80-digit
PG 1
PG 2
PG 3
PG 2 set position
PG 4 set position
10.553 17.949
APG shift start position
APG shift area
PG 4
0-digit
APG Cam
Cam face
PG 4
PG 3
PG 2
PG 1
PG 4
PG 3
PG 2
PG 1
PG 1 set position

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
