EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 121
Confidential
ADDITIONAL LIFT ERROR (1)
 Error name
 LFT2 PID driving time error (error code: 000180)
 Cause
 The drive time of the Optional LIFT Motor has exceeded a fixed value.
 Suspected cause
 Optional Cassette ASF Motor cable failure
 Optional Paper Cassette Main Board Assy failure
 Troubleshooting
Step Check and measure Yes No
1
Check the Optional Cassette ASF Motor cable.
Is the optional cassette ASF motor cable (CN13) connected properly? (Refer
to P. 592)
Go to step 2
 Correctly insert the optional cassette ASF
motor cable (CN13).
 Replace the Optional Cassette Unit in the
case of cable damage.
2
Replace the Optional Paper Cassette Main Board Assy.
Does the error occur after replacing the Optional Paper Cassette Main Board
Assy?
Replace the Optional Cassette Unit.
(If the trouble is not resolved, contact the
EPSON Service Department.)
End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
