Adjustment Adjustment and Inspection Overview 552
Confidential
7.1 Adjustment and Inspection Overview
Thischapterdescribestheadjustmentandinspectionitemsrequired during repair
work.
7.1.1 Operating Environment
The operating environment for the Adjustment Program is as follows.
 OS: Windows vista, 7, 8, 8.1, 10
 Interface: USB
7.1.2 Tools and jigs
The following tools and jigs are required for adjustment and inspection.
 Jigs
Note 1 : “O”: Commercially available ones are acceptable.
2 : EPSON provides the tools listed with EPSON part code.
Jig Availability Part code Remark
Teflon tape O 1706715
Thickness gauge O -
Scale O -
Leak tester sheet front - 1684353
Leak tester sheet rear - 1684354
