Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 96
Confidential
ADF/SCN ERROR (7)
 Error name
 Paper jam error (error code: 100054)
 Cause
 Occurs if a paper jam occurred in the document feed path of the ADF.
 Suspected cause
 Jammed paper or foreign object remained
 ADF PE Sensor failure
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Visually check the paper feed path.
Is there no jammed paper remaining in the paper feed path?
Go to step 2 Remove the jammed paper or foreign object.
2
Visually check the FFCs of the ADF/SCN Unit.
Check the FFC (thick) in ADF/SCN that is connected to the main board to
make sure that it is not inserted obliquely or disconnected.
Go to step 3
 Properly connect the FFC of ADF/SCN.
 Replace the ADF/SCN Unit if the FFC is
damaged.
3
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Contact the EPSON Service Department. End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
