Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 114
Confidential
ADDITIONAL ASF ERROR (1)
 Error name
 2nd ASF PID driving time error (error code: 000080)
 2nd ASF load position driving time error (error code: 000090)
 Cause
 The drive time of the ASF Motor (Optional Cassette Unit) exceeded the set time.
 Suspected cause
 Cable disconnection or contact failure in the Optional Cassette ASF Motor
 Optional Paper Cassette Main Board Assy failure
 Troubleshooting
Step Check and measure Yes No
1
Check the connection of the optional cassette ASF motor cable.
Is the Optional Cassette ASF Motor Cable (CN13) connected properly?
(Refer to P. 592)
Go to step 2
 Correctly insert the Optional Cassette ASF
Motor Cable (CN13).
 Replace the Optional Cassette Unit in the
case of damage of the motor cable.
2
Replace the Optional Paper Cassette Main Board Assy.
Does the error occur after replacing the Optional Paper Cassette Main Board
Assy?
Contact the EPSON Service Department. End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
