EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 113
Confidential
ASF ERROR (3)
 Error name
 ASF PID excess speed error (error code: 000062)
 ASF load position excess speed error (error code: 000072)
 Cause
 State in which driven at unexpected speed (fast) for control.
 Suspected cause
 Disconnection or contact failure of the ASF Encoder FFC
 ASF gear train part damaged
 ASF Encoder failure
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Check the connection of the ASF Encoder FFC.
Check the ASF Encoder FFC to make sure that there is no disconnection or
contact failure.
Go to step 2
Properly insert the ASF Encoder FFC.
(Replace the Printer Mechanism if the FFC is
damaged.)
2
Check the ASF gear train parts.
Is the ASF gear train parts detached or broken?
Go to step 3
Replace the Printer Mechanism if it drops out,
is damaged, or deviates.
3
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Contact the EPSON Service Department. End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
