EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 115
Confidential
ADDITIONAL ASF ERROR (2)
Error name
2nd ASF PID excess load error (error code: 000081)
2nd ASF PID reverse error (error code: 000083)
2nd ASF PID lock error (error code: 000084)
2nd ASF load position excess load error (error code: 000091)
2nd ASF load position reverse error (error code: 000093)
Cause
Jammed paper remained
ASF Encoder Assy failure
Paper path damaged and feed roller worn out
Gears locking due to foreign object
Locked because ASF gear train part failure
ASF Motor (Optional Cassette Unit) failure
Optional Paper Cassette Main Board Assy failure
Suspected cause
Disconnection or contact failure of the ASF Encoder FFC in the optional cassette
State in which load of ASF (Optional Cassette Unit) motor exceeds expected load
When rotated in the opposite direction to rotation direction
(There was a sudden load error, and the motor rotated in the opposite direction in reaction to it)
Troubleshooting
Step Check and measure Yes No
1
Visually check the paper feed path.
Is there no jammed paper remaining in the paper feed path?
Go to step 2 Remove the jammed paper.
2
Check the Vertical Feed Roller state
The Vertical Feed Roller is not damaged or worn out.
Go to step 3
Clean or replace the Vertical Feed Roller
Replace the Vertical Feed Roller in the case
of damage.
3
Check the ASF gear train parts of the Optional Cassette Unit.
Check the optional cassette ASF wheel column components to make sure that
foreign objects are not stuck, and there is no damage.
Replace the Optional Paper Cassette Main
Board Assy.
(If the trouble is not resolved, contact the
EPSON Service Department.)
Remove the foreign object.
Replace the Optional Cassette Unit in the
case of damage.
To Next Page
