Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 161
Confidential
THE PRODUCT CANNOT BE POWERED ON
 Symptom
The power does not turn on even if the Power button is pressed.
 Cause
 Panel Assy failure
 Relay Cable (Panel to Main) connection failure, disconnection
 Power Supply Assy failure
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Check the Relay Cable (Panel to Main)
Check the Relay Cable (Panel to Main) according to the procedure below.
 Check if the Relay Cable (Panel to Main) is connected correctly.
 Check if the Relay Cable (Panel to Main) is damaged.
Make sure there is no problem in the connection or state of the Relay Cable (Panel to
Main).
Go to step 2
 When the cable is not connected correctly
Reconnect the Relay Cable (Panel to Main) correctly.
 When the cable is damaged
Replace the Relay Cable (Panel to Main).
If the symptom continues to occur, go to step 2.
2
Check with a normal panel unit.
Check by replacing the panel unit with a normal unit (with which normal operation can
be confirmed).
Has the phenomenon been improved upon?
Replace the Panel
Assy. (p. 368)
Go to step 3
3
Check with a normal Power Supply Board.
Check by replacing the Power Supply Board with a normal board (with which normal
operation can be confirmed).
Has the phenomenon been improved upon?
Replace the Power
Supply Assy. (p. 345)
Replace the Main Board Assy. (p. 328)

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
