EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 116
Confidential
ADDITIONAL ASF ERROR (3)
Error name
2nd ASF PID excess speed error (error code: 000082)
2nd ASF load position excess speed error (error code: 000092)
Cause
State in which driven at unexpected speed (fast) for control.
Suspected cause
ASF gear train parts detached or broken
Optional Paper Cassette Main Board Assy failure
Troubleshooting
Step Check and measure Yes No
1
Check the ASF gear train parts of the Optional Cassette Unit.
Is the ASF gear train parts detached or broken?
Go to step 2
Correct any drop-out or shifting.
(Replace the Optional Cassette Unit in the case
of damage.)
2
Replace the Optional Paper Cassette Main Board Assy.
Does the error occur after replacing the Optional Paper Cassette Main Board
Assy?
Replace the Optional Cassette Unit.
(If the trouble is not resolved, contact the
EPSON Service Department.)
End
