EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 123
Confidential
ADDITIONAL LIFT ERROR (3)
 Error name
 LFT2 PID excess speed error (error code: 000182)
 Cause
 State in which driven at unexpected speed (fast) for control.
 Suspected cause
 The Optional Lift Wheel Column components are damaged or a foreign object has entered
 Optional Paper Cassette Main Board Assy failure
 Troubleshooting
Step Check and measure Yes No
1
Check the Lift gear train parts.
Is the Lift gear train parts detached or broken?
Go to step 2
 Correct any drop-out or shifting.
 Replace the Optional Cassette Unit in the
case of damage.
2
Replace the Optional Paper Cassette Main Board Assy.
Does the error occur after replacing the Optional Paper Cassette Main Board
Assy?
Replace the Optional Cassette Unit.
(If the trouble is not resolved, contact the
EPSON Service Department.)
End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
