Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 122
Confidential
ADDITIONAL LIFT ERROR (2)
 Error name
 LFT2 PID excess load error (error code: 000181)
 LFT2 PID lock error (error code: 000184)
 Cause
 The load became unexpectedly high with hopper lift driving.
 State in which load of motor exceeds expected load, and motor does not rotate at all
 Suspected cause
 Foreign object in Paper Cassette

Paper incorrectly loaded or number of sheets loaded exceeds maximum
 Damage to or foreign object trapped in lift gear train parts
 Lift Phase Sensor failure
 Lift Motor failure
 Optional Paper Cassette Main Board Assy failure
 Troubleshooting
Step Check and measure Yes No
1
Check for the Paper Cassette (1)
Check that there is no foreign object in the paper cassette.
Go to step 2 Remove the foreign object.
2
Check for the Paper Cassette (2)
Check that more than the maximum number of sheets of paper is not loaded.
Furthermore, is the paper loaded correctly?
Go to step 3
 Reduce the number of sheets of paper loaded.
 Properly set the paper.
3
Check for the Paper Cassette (3)
Check the hopper-up mechanism of the paper cassette to make sure that it is
working correctly.
(Check if the Hopper operates when the left-side gear of the paper cassette is
touched by hand.)
Go to step 4
 Replace the Paper Cassette if there is an error
in the hop-up action.
 Replace the (1) Lift Up Gear 30T or (2) Lift
Up Sector Gear 40T if the left-side gear of
the Paper Cassette is replaced.
4
Visually check the Lift gear train parts.
Check the Lift gear train parts to make sure that there is no foreign object on
or damage to them.
Go to step 5
 Remove any foreign objects, if present.

Replace the Optional Cassette Unit if the Optional
Lift Wheel Column components are damaged.
5
Check the connection of the Optional Lift Phase Sensor.
Check the connection of the Optional Lift Phase Sensor Connector (CN4),
and make sure there are no problems. (Refer to P. 592)
Go to step 6
Properly connect the Optional Lift Phase
Sensor Connector (CN4).
(Replace the Optional Cassette in the case of
cable damage.)
6
Replace the Optional Paper Cassette Main Board Assy.
Does the error occur after replacing the Optional Paper Cassette Main Board
Assy?
Replace the Optional Cassette Unit. End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
