Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 88
Confidential
4.2.2 Fatal Errors
Table 4-2. Fatal Errors
Error code Error details
Troubleshooting
procedure
100001 ADF PID excess speed detection P. 90
100002 ADF PID reverse detection
P. 91100003 ADF PID lock detection
100005 ADF PID excess load
100006 ADF PID driving time P. 92
100016 HP detection failure P. 93
100017 Contact detection distance exceeded P. 94
100032 LED light failure P. 95
100054 Paper jam error P. 96
100065 FB PID excess speed detection P. 97
100066 FB PID reverse detection
P. 98100067 FB PID lock detection
100069 FB PID excess load
100070 FB PID driving time P. 99
100073 FB BS+ excess speed detection P. 97
100074 FB BS+ reverse detection
P. 98100075 FB BS+ lock detection
100077 FB BS+ excess load
100078 FB BS+ driving time P. 99
190000 Calibration error P. 100
000020 CR PID driving time error P. 101
000021 CR PID excess load error P. 102
000022 CR PID excess speed error P. 104
000023 CR PID reverse error
P. 102
000024 CR PID lock error
000025 CR PID underspeed error P. 105
000030 CR load position driving time error P. 101
000031 CR load position excess load error P. 102
000032 CR load position excess speed error P. 104
000033 CR load position reverse error P. 102
000040 PF PID driving time error P. 106
000041 PF PID excess load error P. 107
000042 PF PID excess speed error P. 109
000043 PF PID reverse error
P. 107
000044 PF PID lock error
000050 PF load position driving time error P. 106
000051 PF load position excess load error P. 107
000052 PF load position excess speed error P. 109
000053 PF load position reverse error P. 107
000060 ASF PID driving time error P. 110
000061 ASF PID excess load error P. 111
000062 ASF PID excess speed error P. 113
000063 ASF PID reverse error
P. 111
000064 ASF PID lock error
000070 ASF load position driving time error P. 110
000071 ASF load position excess load error P. 111
000072 ASF load position excess speed error P. 113
000073 ASF load position reverse error P. 111
000080 2nd ASF PID driving time error P. 114
000081 2nd ASF PID excess load error P. 115
000082 2nd ASF PID excess speed error P. 116
000083 2nd ASF PID reverse error
P. 115
000084 2nd ASF PID lock error
000090 2nd ASF load position driving time error P. 114
000091 2nd ASF load position excess load error P. 115
000092 2nd ASF load position excess speed error P. 116
000093 2nd ASF load position reverse error P. 115
000100 IS PID driving time error P. 117
Table 4-2. Fatal Errors
Error code Error details
Troubleshooting
procedure

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
