Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 110
Confidential
ASF ERROR (1)
 Error name
 ASF PID driving time error (error code: 000060)
 ASF load position driving time error (error code: 000070)
 Cause
 The drive time of the motor exceeded the set time.
 Suspected cause
 Motor cable disconnection or cable contact failure
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Visually check the status and connection of ASF Motor Cable (CN80).
Is the ASF Motor Cable (CN80) connected properly? (Refer to P. 592)
Go to step 2
 Correctly insert the ASF Motor Cable
(CN80).
 Replace the Printer Mechanism if damaged.
2
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Contact the EPSON Service Department. End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
