EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Product Specifications Product Hardware Specifications 14
Confidential
2.1 Product Hardware Specifications
Hardware specifications
Item
Specification
WF-C5790/WF-C5790a/WF-C5710/ET-8700 WF-C5210/WF-C5290/WF-C5290a
Dimension (Stored)
When the stacker is attached 425 mm (W) x 357 mm (H) x 535 mm (D) 425 mm (W) x 357 mm (H) x 535 mm (D)
When the stacker has been removed 425 mm (W) x 357 mm (H) x 434 mm (D) 425 mm (W) x 357 mm (H) x 434 mm (D)
Dimension (Printing)
When the stacker/paper support has been extended
425 mm (W) x 449 mm (H) x 578 mm (D) 425 mm (W) x 449 mm (H) x 578 mm (D)
When a scanner is used 425 mm (W) x 616 mm (H) x 535 mm (D) ---
Weight
Without consumables and options 18.4 kg 15.3 kg
Optional Cassette Unit 4.3 kg
Panel LCD 4.3 inch optical touch panel 2.4 inch color LCD
Power supply rating 100 to 240 VAC
Input voltage range 90 to 264 VAC
Rated current 0.9 to 0.5 A
Maximum rated current 1.1 to 0.6 A
Rated frequency range 50 - 60 Hz
Input frequency range 49.5 - 60.5 Hz
Power consumption
Copying Approx. 25 W Approx. 21 W
Ready mode Approx. 12 W Approx. 7 W
Sleep mode Approx. 1.5 W Approx. 1.2 W
Power off mode Approx. 0.2 W Approx. 0.2 W
Environmental
Operating
Temperature 10 to 35 degrees C
Humidity (without condensation) 20 to 80% RH
Altitude 3,000 m or lower
Stored
Temperature Before opening: -20 to 60 degrees C, After opening: -20 to 40 degrees C
Humidity 5 to 85% RH
Altitude ---
Paper loading capacity
Paper cassette 1 (64gsm) 250 sheets
Paper cassette 2 (optional paper cassette unit)
(64gsm)
500 sheets
