Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 94
Confidential
ADF/SCN ERROR (5)
 Error name
 Contact detection distance exceeded (error code: 100017)
 Cause
 Gradual fitting cannot be performed when gradual fitting drive is performed at the zero-point side.
 Suspected cause
 FW failure
 Wheel column, belt runout
 Troubleshooting
Step Check and measure Yes No
1
Check for the firmware.
Check whether or not the firmware is the latest version.
Go to step 2 Update the firmware.
2
Visually check the FFCs of the ADF/SCN Unit.
Check the FFC (thin) in ADF/SCN to make sure that it is not inserted
obliquely, folded, or damaged.
Go to step 3
 Properly connect the FFC of ADF/SCN.
 Replace the ADF/SCN Unit if the FFC is
damaged.
3
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Contact the EPSON Service Department. End

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
