Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 104
Confidential
CR ERROR (3)
 Error name
 CR PID excess speed error (error code: 000022)
 CR load position excess speed error (error code: 000032)
 Cause
 State in which driven at unexpected speed (fast) for control.
 Suspected cause
 CR Timing Belt detached or broken
 CR Motor failure
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Check the CR Timing Belt
Is the timing belt detached or broken?
Replace the following parts in sequence.
 CR Motor
 Main Board Assy
(If the trouble is not resolved, contact the
EPSON Service Department.)
 When the belt is detached, reattach it.
 When the belt is broken, replace the CR Unit.

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
