8-2. When the screen shown below appears, the storage of check results in
the USB memory is complete.
Figure 4-30. Check Results Storage - Work Procedure (2)
8-3. Press the [#] button and proceed to the End screen.
8-4. On the End screen, press the [Power] button to end “FAX Line
Measurement”.
Figure 4-31. Check Results Storage - Work Procedure (3)
 Sample stored check data
Figure 4-32. Sample stored check data
FAX Line Measurement
Save Result (USB)
Success!
Run:[#]
If you want to go to next step.
Push “Run”
FAX Line Measurement
Finish
Push “Power” to turn off.
No-Line
Line (OnHk)
Line (OffHk)
DT Lv
DT-On
DT-Off
BT Lv
BT-On
BT-Off
IR Freq
IR-On
IR-Off
EXT(OffHk)
: 0.0 - 0.0 [V]
: 48.0 - 48.0 [V]
: 6.0 - 6.0 [V]
: -20.0 [dBm]
: Continuous
: ------- [ms]
: -20.0 [dBm]
: 500 [ms]
: 500 [ms]
: 16.0 [Hz]
: 1000 [ms]
: 2000 [ms]
: 6.0 - 6.0 [V]
