EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 231
Confidential
Figure 6-12. Paper Feed Mechanism (2)
No. Part/Component No. Part/Component No. Part/Component No. Part/Component
1 PF Scale (p. 439) 4 Photo Interrupter (p. 458) 7 Pickup Roller Housing (p. 453) 10 PE Assy (p. 468)
2 PF Encoder Board (p. 439) 5 Paper Feed Roller (p. 458) 8 Retard Roller (p. 453) 11 ---
3 Rear Unit Detection Sensor (p. 439) 6 Rear ASF Solenoid (p. 458) 9 Retard Extension Spring (p. 453) 12 ---
2
1
3
4
5
6
7
8
9
10
