EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Configuration and operating principles Product Configuration (Name of Each Part) 26
Confidential
Figure 3-4. Name of Each Part
Table 3-4. Name of Each Part
No. Name Description
1 Scanner unit (J)
Scans placed originals. Open when removing
jammed paper inside the printer.
2 Printhead Fires ink.
3 Ink supply unit tray Sets an ink supply unit.
4 Front cover (A) Open when replacing ink supply units.
5 Front cover lock Locks the front cover.
