Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Adjustment Adjustment and Inspection Details 565
Confidential
INITIAL SETTINGS
1. After replacing the Main Board Assy, connect the printer and PC, and then turn the
printer on.
2. Start the Adjustment Program, and select “Initial Settings”.
3. In the Initial Settings menu, make sure a check mark has been placed for the
following items.
 EEPROM data initial check
 Product Serial No. (10 digits)
 MAC Address
Figure 7-9. Initial settings screen (1)
4. Enter the product serial No. into the Product Serial No. (10 digits) entry field.
5. Enter the MAC address into the MAC Address entry field.
6. Press the Perform button to execute the initialize the Main Board Assy.
Figure 7-10. Initial settings screen (2)
C H E C K
P O I N T
Execute this function only when the EEPROM backup fails (backup
cannot be performed).
** ** **
**********

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
